EXAMPLE SYSTEM 5: |
| Qty. |
|
Componenets |
| 16 |
|
Sharp 123 watt solar panels |
| 4 |
|
30’ #10-2 MC cable assemblies |
| 1 |
|
16x top-of-pole mount structure
(Yes, DP makes a single rack that will hold 16 Sharp 123’s!) |
| 1 |
|
Outback PSPV combiner box with four 15A breakers
& SOV |
| 1 |
|
Outback MX60 MPPT solar charge controller |
| 1 |
|
Outback OBDC-60 MX60 input breaker |
| 1 |
|
Outback OBDC-70 MX60 output breaker |
| 1 |
|
Outback PS2DC-175 main DC disconnect |
| 1 |
|
Outback OBDC-175 breaker for 2nd inverter |
| 2 |
|
Outback VFX3648 (or GVFX3648) 3600W 48V sine wave
inverters |
| 2 |
|
Outback FXA adapter kits |
| 1 |
|
Outback X-240 transformer |
| 1 |
|
Outback RTS temperature sensor |
| 1 |
|
Outback PS2MP mounting plate |
| 1 |
|
Outback PS2AC-50D main AC input/output/bypass
disconnect |
| 1 |
|
Outback MATE system controller & monitor |
| 1 |
|
1 Outback HUB-4 communications manager |
|
|
|
|
Equipment total = $26,025
($9.74 per watt of rated solar power) Due to
the volatility of battery prices please call for current pricing
on the following "rest of system" components. |
| 12 |
|
Surrette 4KS-25PS 4V 1350 amp-hour batteries |
| 2 |
|
#2/0 AWG 24” battery interconnects |
| 2 |
|
#2/0 AWG 36” battery interconnects |
| 1 |
|
set of #4/0 AWG 10’ inverter cables |
|
|
